| Technical parameters | The rated specification | note |
| Module supply voltage | DC24V±20% | ... |
| Maximum power supply | <4W | ... |
| Balanced power supply | <25W | ... |
| Battery monitoring section | 12 | Single maximum support. |
| Voltage detection range | 1.0～5.0V | ... |
| Voltage detection accuracy | ±0.1% | ... |
| Temperature testing quantity | 12个 | Single maximum support. |
| Temperature detection range | -20～85℃ | ... |
| Temperature detection accuracy | ±1℃ | ... |
| Battery balancing method | Active equilibrium | ... |
| Battery balanced current | 5A±0.2A | ... |
| Input insulation resistance | ≥10MΩ,1000VDC | ... |
| Data communication interface | CAN*1 | ... |
| Communication baud rate | 250Kbps | ... |
| Dry contact output | 2A@250VAC/30VDC | 2 |
| Size and weight | 233×127×44(mm)/1Kg | ... |
| installation | Hangers, wall hangers | ... |
