| Technical parameters | rating | Notes |
| module supply voltage | DC24V ± 15% | ... |
| Maximum power supply | 5W | ... |
| voltage detection range | 0 ~ 1500V | ... |
| Voltage detection accuracy | ± 0.1% FSR | ... |
| current detection range | ± 1000A | ... |
| Current detection accuracy | ± 0.5% FSR | support shunt collection |
| temperature detection range | -20 ~ 85 ℃ | ... |
| temperature detection accuracy | ± 0.5℃ | ... |
| Insulation resistance detection accuracy | 5% | ... |
| Input Insulation Resistance | ≥10MΩ, 1000VDC | ... |
| data communication interface | RS485 * 2, CAN * 3 | ... |
| communication baud rate | 9600bps, 250Kbps (default) | ... |
| wet contact output | 1A @ 24VDC | 1 |
| dry contact output | 2A @ 250VAC / 30VDC | ... |
| switch input | Passive, 12VDC | 4 |
| size and weight | 250 × 95 × 45 (mm) / 1Kg | 4 |
| installation method | wall hang | ... |
